The standing tribune for approximately 3500 persons was dimensioned for a vertical live load of p=7,5kN/m2 and an associated horizontal load of h=0,75kN/m2. The surrounding railings have been designed for the horizontal line load 1,0kN/m according to high crowd. Between several rows separation railings were placed according to the german guidelines for temporary buildings. The statical analysis was done for several statical systems in the lengthwise system.
