Workshop with office and common rooms

Workshop

The workshop has the dimensions 23,5m·35,0m and a roof pitch of 10°. In the workshop a crane operates with a carrying capacity of 10to. The roofing of the workshop was made using thermal roof elements on Wuppermann purlins.

Office and common rooms

For the office and common rooms a calculation for thermal protection was led. The ceiling of the office and the common rooms was made of pre-cast segments (system klee: fixfertig d=20cm). The external walls were held against wind loads using a circulating beam of armed concrete according to DIN 1053. The roof structure above the office and the common rooms consists of timber purlins, which carry the thermal roof as single span girders.

Sketch
